Bore : 100 mm
Stroke : 127 mm
Number of cylinder : 4 Vertical,in line
Cubic capacity : 3/99 Litres
Cycle : 4 Stroke
Induction system : Wastegated turbocharger,with air/air intercooling
Combustion system : Fastram direct injection
Combustion ratio : 17/25:1
Firing order : 2 - 4 - 3 - 1
Direction of rotation : Clockwise viewed from front
Fuel pump: Bosch rotary,with boost control
Governing : Mechanical
Cooling : Liquid,belt driven water pump
Weight : 330 kg ( 727 lb )
Thread from : Metric
Electrical system : 12 Volt ( 24 Volt optional)
Power take-off : From crankshaft axially or radially. Gear driven PTO from timing case on LHS bcncath fucl pump
Air compressors : Bendix 150 with steering pump PTO in tandem
Vacuum pump : Clayton HI75 ( optional )
